10W Moving Animation Laser

Rated Voltage：AC100V -230V ±10％
Rated frequency：50HZ～60HZ
Power consumption：150w max
Laser power：8W-10W
Laser color：RGB
Laser wavelength: red 638±5nm, green 520±5nm, blue 450±5nm
Laser modulated signal: analog modulation or TTL modulation
Scanning: 20kpps vibratory mirror system
Scanning angle: ±20 degrees
Channel: 29CH
Control mode: ILDA/DMX-512signal control/ music control/automatic
X axis angle：540 degrees、rotation speed can adjustment(16 bit)
Y axis angle：270 degrees、rotation speed can adjustment(16 bit)
Cool system：fan
Operating environment：indoor

Parameter

Application

Video Demo

Rated Voltage：AC100V -230V ±10％

Rated frequency：50HZ～60HZ

Power consumption：150w max

Laser power：8W-10W

Laser color：RGB

Laser wavelength: red 638±5nm, green 520±5nm, blue 450±5nm

Laser modulated signal: analog modulation or TTL modulation

Scanning: 20kpps vibratory mirror system

Scanning angle: ±20 degrees
